DESCRIPTION

Basic Info

Model NO.	2.92/SMP-KK
Certification	ISO9001, ISO, RoHS
Gender	Female
Fastening Type	Threaded Connection
Mounting Type	Surface Mount
Insulating Materials	Pei
Contact Finish	Gold
Materials	Stainless Steel
Standard	2.92mm Connector
Frequency Range	DC40GHz
Mating Cycles	>1000 Cycles
Plating of Pin	Au,
Transport Package	Box
Trademark	EZCON
Origin	Changzhou, China
HS Code	8536901900
Production Capacity	2000PCS/Year

Packaging & Delivery

Package size per unit product 10.00cm * 10.00cm * 5.00cm Gross weight per unit product 0.500kg

Product Description

2.92/SMP Precision coaxial connector for microwave applications. The maximum frequency is
40GHz.
Design in accordance with: IEEE287™ -2007
Standard materials and finish

Center conductor	Beryllium copper, gold plated
Insulator	PEI
Outer conductor	Stainless steel, Passivated

Electrical Characteristics

Characteristic Impedance	50Ω
Frequency range	DC-40GHz
VSWR	1.25: 1 max
Insulation resistance	5000MΩ Min
Test voltage	1000V

Mechanical

Coupling torque	1.69N*m max
Mating cycles	1000cycles min

Environmental

Temperature range

-55° C~+155° C
